Mondraker DUNE R

ab 7999,⁰⁰ €

Ausführung wählen:

L (450mm)
Farbe: Obsidian/Yellow/Gray 8048,95 €

Zu den Spezifikationen

Das Mondraker DUNE R ist verfügbar bei: Radladen / Autohaus Teumer GmbH

Dein Standort: DE Standort auswählen

GTIN 8435392892216 ArtNr. 010.25255

Spezifikationen

Rahmen

Rahmen: Stealth Air full Carbon, Updated Zero Suspension System, Mullet, Forward Geometry, internal battery, Boost 12x148mm rear axle

Gabel / Dämpfer

Gabel: FOX 38 Float 3P Performance Grip, 170mm, e-bike tuned, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload Dämpfer: Fox Float X Performance EVOL, 205x65mm. Settings: 2-position compression (Open/Firm), rebound, air preload. Trunnion top mount, 30x8mm bottom bushings - Medium compression, medium rebound, air volume spacer 0.4

Schaltung

Schaltung: Sram GX Eagle,12s - Sram UDH Schalthebel: Sram Trigger NX Eagle, 12s, X-Actuation 1:1, single click

Bremsen

Bremse vorne: Sram DB8 stealth, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads Bremse hinten: Sram DB8 stealth, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads Bremshebel: Sram DB8, SwingLink and lever pivot bearings, tools-free reach and contact point adjust

Laufräder

Felgen: e*thirteen Grappler Core, Hookless 6069 Welded Aluminum 30mm internal width, tubeless ready, 28F spokes 29 front, 27''''5 rear Reifen vorne: Maxxis Assegai 29x2.5WT, tubeless ready, 3C MAXX GRIP compound, DH casing, 60x2TPI, folding bead Reifen hinten: Maxxis Minion DHR II 27’5x2.4 WT, tubeless ready, 3C MaxxTerra compound, DD protection, 2x120TPI, folding bead Nabe vorne: e*thirteen Boost 15x110mm, triple-sealed, fully machined aluminum, IS 6 bolts Nabe hinten: e*thirteen Boost 12x148mm, triple-sealed, fully machined aluminum w/6-degree engagement, IS 6 bolts, HG Freehub Speichen: e*thirteen custom J-bend, triple-butted steel, alloy nipples, nipple washers

Cockpit

Lenker: Onoff S6 1.0 7050 alloy, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 1.5 rise. Vorbau: Onoff S6 30mm 0º, 6061 forged alloy + CNC, 31.8mm barbore Steuersatz: Acros custom IS52/ZS56, 1-1/8", 1.5" head tube, Internal cable routing, sealing plugs without blocklock Griffe: Onoff Forest, CNC lock-on, 135mm

Sattel

Sattel: Fizik Terra Aidon Slim X5 Sattelstütze: Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 140-115mm (388-235mm), M size: 160-135mm (428-255mm), L size: 180-155mm (468-275mm), XL size: 210-185mm (528-305mm)

Antrieb

Kurbelsatz: e*Thirteen Helix Core E*Spec Plus, All sizes: 160mm Antrieb: Sram NX Eagle, 12s, Powerlock Zahnkranz: Sram PG-1230, 11-50T, 12s

Motor

Motor: Bosch Performance Line SX (25Km/h) GEN4 SMART SYSTEM Diagonal, Wide Akku: Bosch Compact Powertube 400Wh Akku-Kapazität (Wh): 400 Display: Purion 400 / Bosch Mini Remote / Bosch System Controller

Allgemein

Gewicht (kg): 19,90
